●Eye safe 1535nm QSW DPSS laser
●Low energy consumption
●Compact designs
●Long lifetime
●Easy to fix and operate
●In-depth customization
Applications：
●Laser measuring tools in several industries like construction, renovation and real estate etc…
●Industrial production process
●Military
●Forestry
●Sports
●3D modeling
Parameters：
Properties | Values | Remarks | |
Wavelength | 1535nm | ||
Range capability | 50m~8000m | 2.3m×2.3m target | |
Accuracy | ±2m | ±1m customizable | |
Repetition Frequency(RF) | 1Hz～10Hz | ||
Accuracy Rate | 98% | ||
Divergence | 0.6mrad | ||
Receiving Aperture | 33mm | customizable | |
Communications Interface | RS422 | ||
Power supply voltage | 28V | Optional 12V | |
Operating Power | 4W | ||
Standby Power | 1W | ||
Dimensions | 86mmx51mmx40mm | customizable | |
Weight | 200g | customizable | |
Operating Temperature | -40°C~+55°C | ||
Cooling method | natural cooling | ||
Note: The target color, sizes, surface shape, atmospheric visibility etc. may have an impact on the measurement range. The specific technical parameters are subject to the product manual and are
subject to change without notice.
