Features:
●Good lattice matching
●Low dielectric constant and low dielectric loss
●The coefficient of thermal expansion is small
●Good chemical stability
●Good thermal stability
Application:
●High temperature superconducting thin film substrate materials
●Low loss microwave applications
●Application of dielectric resonance
LaAlO3 crystal is the substrate material for epitaxial growth of high temperature superconducting thin films and giant magnetoresistance thin films because of its good lattice matching with a variety of perovskite structure materials.
LaAlO3 single crystal is the most important industrial and large-scale high temperature superconducting thin film substrate single crystal material. LaAlO3 crystal is the substrate material for epitaxial growth of high temperature superconducting thin films and giant magnetoresistance thin films because of its good lattice matching with a variety of perovskite structure materials.
At the same time, lanthanum aluminate crystal has low dielectric constant and good microwave dielectric properties, so it is suitable for low loss microwave amplifier and dielectric resonance applications.
We offers a single crystal substrate with a maximum diameter of 3 inches.
Chemical formula | LaAlO3 |
Growth method | Czochralski |
Hardness | 6.5 Mohs |
Hardness | 6.52g/cm3 |
Melting point | 2080℃ |
Coefficient of thermal expansion | 10x10-6/℃ |
loss tangent | ~3x10-42@300K,~0.6x10-4@77K |
Color appearance | Depending on the annealing condition, from Tan to brown |
Size | MaxФ76.2mm(3inch） |
Thickness | 0.5mm/1mm |
Polishing | Single side or double side |
Crystal orientation | < 100 >< 110 >< 111 > |
Crystal angle | It can be customized according to the requirements |
Surface roughness | Ra≤5Å（5μmx5μm） |
Redirection accuracy | ±0.2° |
Redirection edge | 2°（Special requirements up to 1 ° within） |
Packing | Class 100 super clean bag, class 1000 super static chamber |
Note: Parameters above can be customized as required. | |
