● Operates at eye-safe wavelength range of 2μm
● Effective cross relaxation between Tm ions, high quantum efficiency
● High LD pump efficiency
Tm: YAG is an excellent crystal suitable for AlGaAs diode-pumped lasers and generates high power 2μm laser emission. It is widely used in medical, military and meteorological fields. We can produce high-quality Tm: YAG crystals with various shapes such as rod, slab and single-crystal fiber.
Chemical Formula,Crystal:Activator | Y3Al5O12: Tm3+ |
Activator Concentration | Tm3+:0.5%~5% |
Wavefront Distortion | λ/8 per inch @632.8nm |
Dimensions | Diameter:2~10mm , Length:5~150mm |
Tolerances | Diameter+0.00/-0.05mm, Length±0.5mm |
Barrel Surface | Fine ground, Polished, Grooved |
Parallelism | ≤10″ |
Perpendicularity | ≤5' |
Surface Quality | 10-5(MIL-PRF-13830B) |
Chamfer | 0.15±0.05mm |
Anti-Reflection Coating | R<0.20%@2μm |
Note: Parameters above can be customized as required. | |
